INTELLIGENT PORTION CUTTER
CUT28-V/CUT3D28-II
The two-dimensional (three-dimensional) measurement of irregular meat is used, analytical calculation by software, which can get the product cutting length and do multiple degrees (90°, 60°, or 45°) cutting. Then it can make sure each piece with same weight after cutting or other required weight. It can be applied with fresh raw meat(thaw) cutting.
1. Straight knife,Applied to the fish, poultry meat and so on.
2. Spiral blade,Applied to the pork, beef, lamb and so on.
3. Toothed spiral blade,Applied to meat with skin and fascia
Adopting the imported scanning and measurement system, high precision cutting, weight error ≤±2%.
Adopting the floating press belt device.
Applied to the flat product, such as the fish, poultry meat and so on.
Can do the meat cutting by 90°, 60°, or 45°.
Adopting imported module type belt, long life service.
Cutting parameter can be easily adjusted by touch screen.
Cutting by the recipe, and can customize multiple recipes.
Such as:
1. Cutting the whole meat into equal weight according to the set weight arrangement with no waste.
2. Cutting the different weight according to the different position width, maximizing product utilization.
The flexible floating double belt press device, can press tightly of the different shape and thickness products,preventing the product moving during the cutting process.
Applied to the irregular shape product.
The whole belt is easily disassembled and cleaning.
CE approved safety protection device.
Adopting the FESTO pneumatic components, and SIEMENS electrical apparatus.
Adopting the 304 stainless steel and engineering plastics, meet the HACCP requirement.
MODEL: CUT28-V CUT3D28-II
Applied material: Fish, poultry meat Pork, beef, lamb, red meat
Belt width: 254mm 254mm
Belt speed: 5~20m/min 5~20m/min
Weight error: ≤±2% ≤±2%
Cutting speed : 1000刀/min 1000刀/min
Max. product height: 50mm 140mm
Max. product length: 650mm 650mm
Max. product width: 240mm 240mm
Input/output height: 1050±50mm 1050±50mm
Power: 7.55kW 7.55kW
Overall dimension: 2512×1200×1680mm 2512×1340×1680mm
